Hyper Hemispheric Dome Lens

Overview of Hyper Hemisphere Dome Lens

ATOPTIK's Hyper Hemisphere Dome is an optical element with higher precision and a unique geometric design. Compared to standard hemisphere lenses, the hyper hemisphere lens offers improvements in shape and is typically used in high-end optical applications that require a wider field of view, higher light transmission, and lower optical distortion. It plays a crucial role in modern high-precision optical systems and is widely used in protecting optical sensors, laser systems, drone cameras, and imaging devices in extreme environments.

Specifications of Hyper Hemisphere Dome Lens

Features of Hyper Hemisphere Dome Lens

• Improved Hyper Hemisphere Design

• Compared to standard hemisphere lenses, the hyper hemisphere lens has an improved shape with higher optical precision and a wider field of view. Its unique spherical design provides a larger field of view and effectively reduces optical distortion and reflection losses.

• This design helps improve image clarity and accuracy, especially in high-resolution imaging and high-quality image sensing, significantly reducing image distortion.

• High Light Transmission and Low Optical Distortion

• ATOPTIK's hyper hemisphere lenses use high-quality optical materials such as sapphire, fused silica, and BK7 optical glass, offering excellent light transmission performance.

• Custom anti-reflection (AR) coatings can be applied to increase light transmission and reduce reflection losses. Coating wavelengths typically cover UV to NIR to meet the needs of various optical applications.

• Exceptional Mechanical Strength and Durability

• Sapphire materials have extremely high hardness and wear resistance, ensuring stable performance under high impact, high pressure, and extreme temperature conditions. Fused silica is suitable for high-temperature environments with low thermal expansion, maintaining optical stability.

• These hyper hemisphere lenses can be widely used in harsh environments such as deep-sea, high temperatures, and chemical corrosion.

• High-Precision Manufacturing and Customization Options

• ATOPTIK offers a wide range of diameters (from a few millimeters to several hundred millimeters) and wall thickness options to meet various optical system and application needs.

• Customization services are available, including mirror accuracy, material selection, coating, and thickness, ensuring that specific technical requirements are met.
