Right Angle Prism

Overview of Right Angle Prism

ATOPTIK offers both uncoated and coated versions of these prisms, with options for broadband antireflection coatings (-A: 350–700 nm, -B: 650–1050 nm, -C: 1050–1700 nm) applied to either the hypotenuse or both legs, minimizing surface losses and enhancing optical performance. These prisms are ideal for applications that require precise beam bending, image inversion, or beam displacement. They are commonly used in imaging systems, laser applications, and precision optical devices.

Additionally, ATOPTIK provides custom coatings to meet specific needs, such as UV-VIS, NIR, or laser line coatings, ensuring the prisms perform optimally across various wavelengths. These prisms can be used to redirect light in systems such as laser cavities, interferometers, and spectroscopy, offering excellent performance for high-precision testing and measurement.

With a focus on quality and reliability, ATOPTIK's right-angle prisms are well-suited for applications in research, industrial optics, and scientific instrumentation, providing superior control over light direction and image formation in a wide range of optical systems.

Specifications of Right Angle Prism

Features of Right Angle Prism

• Light Path Deviation: These prisms can deviate light by 90° or 180°, depending on the orientation of the input light, making them versatile for redirecting beams or altering image paths.

• High-Quality Materials: ATOPTIK’s right-angle prisms are fabricated from premium materials such as N-BK7, UV fused silica, CaF2, and ZnSe, ensuring excellent optical performance across UV, visible, and infrared wavelengths.

• Custom Coatings: Available uncoated or with broadband antireflection coatings (-A: 350–700 nm, -B: 650–1050 nm, -C: 1050–1700 nm), these coatings are applied to the hypotenuse or both legs to reduce surface losses and improve light transmission.

• Wide Range of Sizes: ATOPTIK offers right-angle prisms in sizes ranging from 3 mm to 60 mm, accommodating a variety of optical systems and requirements.

• Imaging Control: These prisms produce inverted or reverted images depending on their orientation. When used in pairs, they are perfect for beam displacement and image manipulation applications.

• High Precision: Designed for high-precision applications, these prisms provide consistent performance in demanding environments, such as laser systems, interferometers, and optical testing instruments.

• Versatility: Ideal for use in beam redirecting, chromatic dispersion demonstrations, laser cavities, spectroscopy, and more, ATOPTIK’s right-angle prisms are critical components in advanced optical systems.

Catalogue of Right Angle Prism
